Drowsiness and Distraction Detector CDP-550A for Industrial Vehicles

470,00 388,43 without vat

This advanced fatigue and distraction digital monitor can prevent serious driving accidents

This digital analyzer specifically designed for industrial vehicles constantly monitors all the facial gestures of the driver. Through a complex facial recognition algorithm, it detects signs of tiredness, drowsiness or distractions, even with the use of sunglasses or at night.

Simple and effective, with practically immediate danger detection. Warnings include powerful sound alerts, LED flashes and an optional seat vibration system.

With this real-time driving monitoring system, we can prevent serious traffic accidents that, according to DGT reports, cause one in three fatal accidents. (See this news about Distractions cause one in three fatal accidents. Spanish)

It is especially suitable for all types of drivers, especially people with high risk exposure due to fatigue or distractions while driving.

In stock

Description

Drowsiness and Distraction Detector CDP-550A for Industrial Vehicles

ADDITIONAL INFORMATION:

  • Intelligent facial recognition image monitoring algorithm.
  • Intuitive intelligent recognition system that contrasts with other similar recognition systems such as LDWS.
  • Detection and warning of drowsiness, fatigue, distraction, smoking behind the wheel, and using a mobile phone while driving.
  • Cognitive operating scenario for early warnings through LEDs and speakers.
  • High-power infrared LED lights available at night and in tunnels.
  • Eliminating irregular sunlight reflections, using special filters.
  • Detection of glasses and sunglasses (excludes mirror and safety goggles).
  • Automatic sensitivity adjustment according to vehicle speed. With the GPS module, this operation is more precise and professional, minimizing possible false warnings in city driving, as a variable coupling of the device occurs at the speed of the vehicle.
  • Silence and volume control in 5 steps including mute, as well as the possibility of overriding the button to prevent unwanted user handling.
  • Improvements and new features available by downloading the Firmware update via USB micro-connector.
  • Works with both DC12V and 24V, suitable for any vehicle.
  • Exclusive support for easy installation and adjustment.
  • Supports various USB accessories (LED warning and vibration lights, etc.)
  • Inter-operation with external devices, such as car navigators and dashboard security cameras, etc. (Optional)
  • Connecting with an external GPS (included)

TECHNICAL CHARACTERISTICS

  • Micro BGA with ARM9 SoC
  • ¼ -inch lens
  • CMOS D1 image processor
  • Interface with I/O and external USB (UVC)
  • Invisible infrared LEDs
  • Operation status LED (green/blue/red)
  • Audio: Micro-speaker (max. 95 dB)
  • Sound via audio CODEC
  • Communication port via UART (RS232) (optional converter at TTL levels)
  • Video output (CVBS at USB)
  • GPS speed signal and (pulse speed / brake / stop)
  • Circuit protection against voltage/current surge, reverse voltage and wave noise minimization
  • Input voltage: DC 12V / 24V
  • Maximum power consumption 4W
  • Size: 126x83x38mm
  • Net weight: 150g (main body)
  • Black color
  • Operating temperature: -20 ~ + 70ºC
  • Approved by KC/FCC/CE and in compliance with RoHS

See this news about Distractions cause one in three fatal accidents. Spanish)
