Description
MC-820E 2K 30fps Professional Body Camera Bodycam.
The MC-820E professional body camera is an advanced video recording solution designed for demanding operating environments, where reliability, image quality and real-time connectivity are critical.
Equipped with a comprehensive management platform compatible with Windows, Android and iOS, it allows the visualization and transmission of video in real time, as well as centralized management of devices, improving operational control and traceability of events.
The MC-820E offers Full HD 1080P AHD resolution, ensuring sharp and detailed images even in low-light conditions thanks to its high sensitivity of 0.1 lux and advanced technologies such as D-WDR and automatic day/night switching. The electronic shutter and automatic white balance ensure consistent image quality without the need for manual adjustments.
It features a 6.0mm lens with a 52° horizontal field of view, optimized to capture scenes with precision and minimal distortion, with alternative 2.8mm and 3.6mm options depending on operational needs. Its 12V power supply and the option of installation in vehicles via windshield mount expand its versatility, allowing it to be used in both personal operations and on-board applications.
In addition, the MC-820E has an optional docking station that allows the simultaneous charging of the battery and the automatic download of videos, facilitating the management of evidence, reducing operational times and ensuring the continuous availability of the device.
The MC-820E is the ideal tool for law enforcement, transportation, emergency services, and corporate environments that require reliable audio-visual evidence, efficient remote management, and maximum operational robustness.
- Off-line model: No data connection to the platform with local operation via Wifi and Bluetooth
- Online model with SIM: 12 months of service with data connection with GPS tracking, real-time video from APP and Web Platform, real-time alerts and audio with video and two-way voice. The service offered includes 12 months of license to use the platform/server and data SIM with a capacity of 10GB per month
Management APP for Windows // Android // IOS:
Key features:
- With real-time video and management platform for Windows/Android/IOs
- Resolution: 1080PAHD
- Minimum illumination: 0.1 lux
- Electronic Shutter (Auto), White Balance (Auto)
- D-WDR, change from day to night
- 6.0mm lens (2.8 and 3.6mm optional)
- HFOV 52°
- 12V power supply
- Option for vehicles with windshield mount
Real-time HD video + AI recognition
- 2K resolution (2560×1440 at 30 fps) with H.265 compression for efficient use of bandwidth and storage.
- Optional facial recognition with offline alarm capabilities: Enables immediate identification without network dependency, which is crucial for security operations.
Rugged Military Grade + Professional Durability
- IP66 waterproof and dustproof rating and 2-meter drop protection – designed to withstand extreme environments (-20 °C to +55 °C).
- Critical for field use in the public safety, law enforcement, and industrial sectors where devices face harsh conditions.
Product video
2K @30fps body camera with MT6769 chip, 3.0″ HD touchscreen and up to 512GB of storage, and also has IP66 protection for all environments. See the video for actual usage.
Law enforcement and public safety
Industrial and Utility Inspections
Emergency and Disaster Response
Technical Specifications:
Hardware:
| Operating System | Industrial Android 12.0 |
| Chip SOC | MT6769 8 Core CPU 64 bit, 2GHz. 12nm |
| Internal storage | 3G + 32G eMMC (4+64/4+256 as optional) |
Network:
| Bluetooth | Includes |
| Position | Supports GPS/BDS/GLONASS (optional) |
| WiFi | 2.4G/5.8G Wifi 5 ac, support IEEE802.11 ac/a/b/g/n |
| 4G | LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28ALTE TDD: B34/B38/
B39/B40/B41WCDMA: B1/B5/B8 |
Cameras:
| Effective pixels | 4 megapixels |
| Video Resolution | 2560×1440/30fps1920×1080/30fps1280×720/30fps |
| Video Format | MP4 |
| Compression | H.264/H.265 |
| Dual current | Supports Permanently Coded Dual Stream |
| Photo format | JPG, 48 megapixels |
| Secondary camera | 8MP |
| Rear camera | 2MP |
Others:
| Monitor | 3.0 inch HD touch screen (480*800) |
| SIM card | Integrated Nano Card |
| TF Card | Integrated TF Card/64GB (Scalable to 256GB) |
| G-Sensor | Includes |
| NFC | Available (optional) |
| USB | Type-C |
| Flashlight | It provides |
| Laser Light | Available (optional) |
| Red and blue warning lights | Built-in |
| IR Night Vision | 4 infrared lights, the recognition range can reach 3 meters for
faces, and the detection range can reach 10 meters for the human body |
